Additional information
| Brand | Omron |
|---|---|
| Sensor Type | Pressure sensor |
| Power supply voltage | 12 to 24 VDC ±10% with a ripple-(p -p) of 10% max. |
| Current consumption | 50 mA max |
| Applicable fluid | Non-corrosive gas and non flammable gas |
| Residual voltage | 1.0 V max. with a load current of 100 mA or 0.4 V max. with a load current of 16 mA |
| Indicator lamp | Orange LED indicator (OUT1:it when digital output is ON) |
| Protection circuits | Reverse polarity protection, load short-circuit protection |
| Ambient temperature | Operating: -10 to 55°C with noicing) |
| Ambient humidity | Operating: 25% to 85% (with no condensation) |
| Storage temperature | -25 to 65°C |
| Accessories | Mounting Brackets (A and B) |
