Additional information
| Brand | Omron electronic |
|---|---|
| Product Category | General Purpose Relays |
| Coil Voltage | 24 VDC |
| Relay Contact Form | 1 Form C (SPDT-NO, NC) |
| Contact Current Rating | 10 A |
| Mounting Style | Through Hole |
| Coil Resistance | 1.6 kOhms |
| Coil Current | 21.8 mA |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Series | G2R |
| Length | 29 mm |
| Width | 13 mm |
| Height | 25.3 mm |
| Contact Form | SPDT (1 Form C) |
| Power Consumption | 530 mW |
| Part # Aliases | G2R1DC24 G2R-1-DC24-BY-OMI G2R1DC24BYOMI |
| Unit Weight | 17 g |
