Description
TYPE DESCRIPTION
HW functional status 01
Firmware version V2
Programming package STEP 7 V5.2 + SP1 or h higher with HW update
Supply voltage
Rated value (DC) 24 V
permissible range, lower limit (DC) 20.4 V
permissible range, upper limit (DC) 28.8 V
external protection for power supply lines 2 A min.
(recommendation)
Input current
Current consumption (rated value) 0.8 A
Current consumption (in no-load operation), typ. 60 mA
Inrush current, typ. 2.5 A
I²t 0.5 A²·s
Power loss
Power loss, typ. 2.5 W
Memory
Work memory
● integrated 128 Kbyte; For program and data
● expandable No
Load memory
● Plug-in (MMC) Yes
● Plug-in (MMC), max. 8 Mbyte
● Data management on MMC
(after last programming), min.10 y
Dimensions
Width 40 mm
Height 125 mm
Depth 130 mm
Weight, approx. 290 g
